Red Wing 26 Dental Lathe (Handler)
26 Red Wing Lathe
A full 1/4 HP, 1725/3450 rpm two speed polishing lathe with 6” [15.2cm] shaft height (115 Volts/60Hz). Designed and built for use as a polishing lathe, its tapered shafts will accept
standard dental tapered chucks.
The 6” [15.2cm] shaft height of the 26 will allow the technician to utilize larger diameter
buffing wheels for pumice and dry polishing operations.This unit may be supplied with 1/2” [1.3cm] straight shafts when specified.
Available in 115 Volts/ 50Hz 26A, 220 Volts/50Hz 26E and 220 Volts/60Hz 26C at
NOTE: Specify No. 26S for motor with 1/2” [1.3cm] straight shafts.
Shipping Wgt.: 41 lbs [18.6 Kg]
Unit Dimensions.: 15 1/2” long x 8” wide x 9” high [39cm x 20cm x 23cm]
