Dental Air Abrasion System AQUACUT QUATTRO

LION'S DENTAL SUPPLY & EQUIPMENT

Quality Dental Equipment, Autoclaves & Supplies...All at the Lowest Prices!!

Dental Air Abrasion System

Aquacut Quattro Air Abrasion System (Velopex)

The NEW approach to preventative and conservative dentistry!

The AQUACUT’s unique fluid curtain suppresses the powder emissions common with air abrasion units from the past,
while simultaneously increasing cutting efficiency by constantly removing debris created during the cutting process.
The use of fluid reduces the need for high air pressure levels, thereby increasing patient comfort.
So how is it used? … When your patient sits down in the dental chair, you are able to perform a fast and effective cleaning of the oral area.
This will present you with a clearer indication of the patient’s dental condition.
At the turn of a switch, … the AQUACUT changes into a powerful cutting tool that will in many instances cancel the need to use the dental turbine.
It is a non-contact instrument, there is no vibration, heat generation or turbine noise. most cases there is no need for an anesthetic.

AQUACUT “QUATTRO”

(VELOPEX)

reg $ 5,999

SALE $ 4,399

PRICE DROP ALERT

What is fluid/air abrasion ?

The Aquacut Quattro is a unique new patented generation of cutting
tool, taking the original concept of air abrasion and with the addition
of fluid, creating Aquabrasion, a far more efficient and gentle technology.
Besides functioning as a cutting tool, the Aquacut also cleans, polishes
and dries.

Advantages of the Aquacut Quattro:

Conservative, tooth-friendly dentistry. No chipping or stress fractures,
and minimal removal sound tooth material
Quick and versatile – reduced treatment times
Multiple quadrants treatable on a single visit
A must for modern adhesive dental techniques
Ability to cut, polish, clean and dry
Incorporates advanced patented technology

Aqucut Quattro Handpiece

Aquacut Quattro Replacement Cartridges

POWDER MANAGEMENT SYSTEM

Sealed, self-contained disposable powder cartridges allow quick and measured refills. An inbuilt feed system insures there

is zero maintenance in this critical area as the cartridges can simply be removed and replaced. This system also allows for

a quick change between powder grades. Powders are available in 53 micron (red cartridge) and 29 micron (blue cartridge)

of Aluminum Oxide for cutting or a Sodium Bicarbonate powder (clear cartridge) for cleaning and polishing.

HANDPIECES

With performance in mind, the ergonomic design allows for comfortable operation in the hand and mouth without sacrificing

accuracy or control. The low resistance nozzle and long-life tungsten tip ensures the handpiece is a high performance precision

instrument. The Autoclave-safe handpiece is made more versatile with a quick release system and comes in two tip sizes: .

I/ASS8090A - BLUE 0.5MM, I/ASS8092A - GOLD 0.8MM, I/ASS8089A - GREEN 0.4MM and I/ASS8091A - SILVER 0.6MM

Air pressure and powder levels are quickly calibrated through a simple-to-use control panel and a powder selection switch allows

instant change from cutting to polishing.
The unique foot control enables the operator to choose instantly any function, enabling all procedures to be carried out through a

SINGLE handpiece, thus speeding up treatment and reducing fatigue.

Aquacut Quattro System

Aquacut Quattro Handpiece Tips

AQUACUT QUATTRO SPECIFICATIONS
External Supplies: Clean, dry, compressed air, 6 bar (90psi) minimum, 7.5 bar (110psi) maximum. Inlet air supply connection Ø 4mm
push-in fitting.

Foot Control: Three-way multi-functional foot valve for cut, wash and dry control. 2m (6ft), three-core pneumatic supply tube.
Output Pressure: Infinitely variable cutting/polishing air pressure between 0 - 7 bar (100psi), controllable via rotating switch and
pressure gauge.

Cutting Media: 53 and 29 micron Aluminium Oxide. Powder rate infinitely variable between 0 and 6g / min (0.2oz) via
rotating switch and pressure gauge.

Polishing Medium: Sodium Bicarbonate.
Handpiece: Anodised Aluminium with separate integral powder and fluid channels (both operated by foot control). Nozzles
made from stainless steel tube with Tungsten Carbide tip. Handpieces incorporate quick release system for
convenient changeover of cutting sizes.

Colour coded handpieces for simple tip-size identification:

Silver - 0.6mm (supplied with the Aquacut QUATTRO)
Purple - 0.3mm (optional extra)
Green - 0.4mm (optional extra)
Blue - 0.5mm (optional extra)
Gold - 0.8mm (optional extra)
